Trek Fuel MX 9 XT Gen 7

Trek Fuel MX 9 XT Gen 7
$4,999.99
Color: Lithium Grey/Trek Black Splatter
Size: Small
Wheel Size: 29-inch front / 27.5-inch rear
Please select options Unavailable

Details

Fuel MX 9 XT is a playful trail bike made for hunting down side hits and chasing chaos. Its Alpha NEXT Platinum aluminum frame it paired with a Fox Factory suspension package (150mm rear, 160mm front) and MX wheels for a ride that's flickable and zippy. A mechanical Shimano XT 12-speed drivetrain gives you clean, reliable shifting and 4-piston XT M8200 brakes provide excellent modulation and stop-on-a-dime power.

Frame SizeSmallMediumLargeX-Large
Wheel size (in) 29"/27.5" 29"/27.5" 29"/27.5" 29"/27.5"
Seat tube (cm / in) 37.0 / 14.57 40.0 / 15.75 42.0 / 16.54 45.5 / 17.91
Seat tube angle (degree) 72.3 72.3 72.3 72.3
Effective seat tube angle (degree) 78.3 77.5 77 76.6
Head tube length (cm / in) 9.5 / 3.74 11.0 / 4.33 12.5 / 4.92 14.0 / 5.51
Head angle (degree) 64.2 64.2 64.2 64.2
Effective top tube (cm / in) 54.9 / 21.61 58.4 / 22.99 61.8 / 24.33 65.2 / 25.67
Bottom bracket height (cm / in) 34.3 / 13.50 34.3 / 13.50 34.3 / 13.50 34.3 / 13.50
Bottom bracket drop (cm / in) 3.1 / 1.22 3.1 / 1.22 3.1 / 1.22 3.1 / 1.22
Chainstay length (cm / in) 43.4 / 17.09 43.4 / 17.09 43.9 / 17.28 44.4 / 17.48
Offset (cm / in) 4.4 / 1.73 4.4 / 1.73 4.4 / 1.73 4.4 / 1.73
Trail (cm / in) 13.2 / 5.20 13.2 / 5.20 13.2 / 5.20 13.2 / 5.20
Wheelbase (cm / in) 119.1 / 46.89 122.8 / 48.35 126.4 / 49.76 130.1 / 51.22
Standover (cm / in) 75.2 / 29.61 74.9 / 29.49 75.2 / 29.61 76.3 / 30.04
Frame reach (cm / in) 42.6 / 16.77 45.6 / 17.95 48.2 / 18.98 50.7 / 19.96
Frame stack (cm / in) 61.3 / 24.13 62.7 / 24.69 64.1 / 25.24 65.4 / 25.75
Frame SizeSmallMediumLargeX-Large
Rider height (cm / in) 155–165 / 61–65 165–177 / 65–70 177–188 / 70–74 188–195 / 74–77
Inseam (cm / in) 74–78 / 29–31 79–83 / 31–33 84–89 / 33–35 89–91 / 35–36

Specs

Frame Alpha NEXT Platinum aluminum, internal storage, ZS headset, adjustable leverage rate, guided internal routing, interchangeable alloy rocker link, interchangeable lower shock mount, downtube guard, shuttle guard, BSA 73, ISCG 05, ABP, UDH, Boost148, adaptable travel 145mm-160mm
Fork Fox Factory 36, Float EVOL air spring, GRIP X2 damper, 44mm offset, Boost 110, 15mm Kabolt X axle, 160mm travel
Rear Shock Fox Factory Float X, 205mm x 60mm
Wheels Front: Bontrager Line Comp 30, Tubeless Ready, 6-bolt, Boost110, 15mm thru axle, 29'' Rear: Bontrager Line Comp 30, Tubeless Ready, Rapid Drive 108, 6-bolt, Shimano MicroSpline freehub, Boost148, 12mm thru axle, 27.5''
Tires Front: Maxxis Assegai, tubeless ready, 3C, EXO+ casing, MAXXGRIP, folding bead, 29x2.5'' Rear: Maxxis Minion DHR II, tubeless ready, 3C, EXO+ casing, MAXXTERRA, folding bead, 27.5x2.5''
Bottom Bracket Shimano BB-MT501 BSA
Crankset Shimano XT M8120, 30T, 55mm chainline, 170mm length
Shifters Shimano XT M8100, 12 speed
Rear Derailleur Shimano XT M8100, long cage
Cassette/Freewheel Shimano XT M8200, 10-51, 12 speed
Chain Shimano XT M8100, 12 speed
Brakes Shimano XT M8200 4-piston hydraulic disc
Rotors Front: Shimano RT86, 6-bolt, 203mm Rear: Shimano RT86, 6-bolt, 180mm
Handlebars Race Face Turbine, alloy, 35mm, 40mm rise, 780mm width
Tape/Grips Trek Line Elite, lock-on
Stem Bontrager Elite, 35mm, 0 degree, 45mm length
Seatpost Small: Bontrager Line Dropper 150mm Travel, MaxFlow, internal routing, 34.9mm, 410mm length, Medium: Bontrager Line Dropper 170mm Travel, MaxFlow, internal routing, 34.9mm, 450mm length Large, X-Large: Bontrager Line Dropper 200mm Travel, MaxFlow, internal routing, 34.9mm, 515mm length
Saddle Verse Short Comp, steel rails, 145mm width

* Subject to change without notice.

Part Numbers

Option UPC MPN Store SKU
Lithium Grey/Trek Black Splatter / Small / 29-inch front / 27.5-inch rear 197216278481 5340492 FUE425358027
